Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports

Shenzhen Optfocus Technology Co., Ltd.
Contact Now
    Buy cheap Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports from wholesalers

    Buy cheap Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports from wholesalers
    • Buy cheap Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports from wholesalers

    Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports

    Ask Lasest Price
    Brand Name : OPTFOCUS
    Model Number : OFS-SF2T3-20
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 5
    Price : Negotiable
    • Product Details
    • Company Profile

    Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports

    OFS-SF2T3-20
    3ports 10/100M + 2port 100M SM 20KM Fiber Switch


    Technical Specifications

    Product Name

    3-port 10/100Mbps + 2-port 100Mbps Fiber

    Product Model

    OFS-SF2T3-20

    Network Protocols

    IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;IEEE802.3u;100Base-TX/FX;IEEE802.3ab 100Base-T; IEEE802.3z 100Base-X; IEEE802.3x;

    Network Media

    10BASE-T: Cat3,4,5 UTP(≤100 meter)
    100BASE-TX: Cat5 or later UTP(≤100 meter)

    Fiber Media

    Multi-mode: 2KM
    Single-mode: 20/40/60/80/100KM
    Fiber port :SC/ST/FC Optional

    Performance Specification

    Bandwidth: 1Gbps
    Packet Buffer Memory:1M
    Packet Forwarding Rate:148800pps/port
    MAC Address Table:1K

    Forwarding Mode

    Store-and-Forward

    LED Indicators

    Power: PWR; FX Link;TP Link/Act

    Power Supply

    Input: AC100 ~ 250V,
    Output:DC5V 2A.

    Max power

    4W

    Environment temperature

    0 ~ +55

    Storage temperature

    -20 ~ +70℃

    Humidity

    5% ~ 90%

    Dimensions

    26 × 70 × 93mm


    Feature:
    l 3 Port 10/100Mbps with Auto Uplink™ , 2 port 100Mbps Fiber port.
    l Automatic MAC address learning and aging
    l 10/100Mbps Auto-negotiation , auto-MDI-MDI-X
    l LED indicators for monitoring power/link/activity
    l Supports10/100Mbps-Full/Half-duplex
    l Supports Wall-mount and DIN-Rail installation ,Optional.
    l Supports Broadcast Storm Control
    l Excellent heat elimination without cooling fan.
    l Apply to Urban Intelligent Traffic Monitoring System (ITS), Safe City.
    l Harsh environment or higher requirement
    l 10℃-55℃operating temperature range.


    Package Dimension:

    Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports

    Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports

    Application

    Lightweight Fiber Optic Gigabit Ethernet Switch 2*100Mbps Optical Ports 3*10/100Mbps RJ45 Ports
