OFSE3504
4*EPON+4GE RJ45
Description:
The OFSE3504 design chassis OLT device provides 4 EPON ports,
4*10/100/1000Mbps RJ45 ports and 4 uplink GE SFP ports.GPON OLT's height is 1U, easy
to install and save space. Each PON supports up to 1:64 spectral
ratio, and the whole machine can support 256 ONU terminals under
full configuration.
OFSE3504 uses advanced technology to support SLA and DBA to
maintain the QoS characteristics of Ethernet.For commercial and
network digital management, we provide a comprehensive, smart,
strong, advanced and professional solution.
Implementation projects for "automatic allocation" and "power
consumption information collection"
Technical Specifications
Upstream PON interface | 4 EPON interface, SC single-mode/single-fibre,1.25Gbps |
Wavelength | Tx 1310nm, Rx 1490nm |
Optical output power | -1~+4dBm |
Receiving sensitivity | <-26dBm |
Farthest distance | 20km between OLT and ONU |
Optical interface | SC/UPC connector |
Downstream LAN interface | 4*FE/GE auto adaptive Ethernet interfaces, Full Duplex/Half Duplex,
RJ45 connectors |
VLNA | 4K VLAN table items VLAN based on port, MAC, protocol and IP subnet. port QinQ and flexible QinQ (StackVLAN) VLAN Swap and VLAN Remark GVRP t the addition, deletion and replacement of VLAN based on ONU business flow. |
Security strategy | Support AES-128,data encryption for both upstream and downstream Support dynamic update of key |
Management maintenance | Centralized OLT management based on OAM WEB,CLI |
Indicators | 7 indicators, for status of power supply, PON port and 4 Ethernet port. |
power supply | AC:90~260V,47~63Hz DC:-36V~-72V |
Chipset | zte chipset |
Power switch | 1 |
Power consumption | 22.5W |
Operating condition | Operating temp: -5~+55℃
Operating humidity:10~90%(non-condensed) |
Storing condition | Storing temp: -30~+60℃
Storing humidity:10~90%(non-condensed) |
Dimension | 442mm*300mm*44mm(length*width*height) |
Net weight | 1.84Kg |
Feature:
l Plug and play, features auto-detecting, auto-configuration, and
auto firmware upgrade, etc.
l China Telecom / China Unicom GEPON interoperability standards
l Support for the transmission distance of 20Km on a single root
fiber
l Supporting 64 terminals of passive optical splitter on single
optical fiber
l Support 128Bits up and down three churning encryption functions
l Support ONU terminal legitimacy authentication, illegal ONU
registration events reported
l DBA algorithm supporting dynamic bandwidth allocation, granularity
64Kbit/s
l Support standard OAM and extended OAM management functions
l Support ONU software batch upgrade, timing upgrade, real-time
upgrade support PON port luminous power, accept optical power
detection
l Support for command line interface (CLI), Console port, Telnet and
WEB configuration management.
l Support EAPS and GERP enhanced Ethernet ring network protocol (loop
healing time <50ms) support.
Physical Pic Reference :
